X u
z 드 u u s a |
1.1 |
制造商
Manufacturer |
ZMK | ||||
| 1.2 | 制造商型号
Manufacturer’s type designation |
RKF30 | RK F35 | RKF38 | |||
| 1.3 | 驱动方式
Drive type |
电动
Electo |
|||||
| 1.4 | 操作方式
Operator type |
座驾式
Seated |
|||||
| 1.5 | 额定载荷
Rated capacity/rated load |
Q | kg | 3000 | 3500 | 3800 | |
| 1.6 | 载荷中心距
Load centre distance |
C |
mm |
500 | |||
| 1.7 | 前悬距
Load distance, centre of drive axle to fork |
x |
mm |
477 | 482 | 482 | |
| 1.8 | 轴距
Wheelbase |
y |
mm |
1750 | 1750 | 1780 | |
|
三 咖阖 M |
2.1 | 总重
Servicc Weight |
kg | 4500/4290 | 4810/4600 | 5240/5000 | |
| 2.2 | 桥负载，满载前／后
Axle loading,laden front/rear |
kg | 6710/790 | 7590/720 | 8150/890 | ||
| 2.3 | 桥负载，空载前／后
Axle loading, unladen frontrear |
kg | 2010/2490 | 2070/2740 | 2220/3020 | ||
|
湖 |
3.1 | 轮胎
Tyres |
前轮充气胎/后轮实心胎 | ||||
| 3.2 | 轮胎尺寸，前
Tyre size,front |
28×9-15-14PR | 28×12.5-15-2414PR | ||||
|
3.3 |
轮胎尺寸，后
Tyre sizc,rcar |
18×7-8 | 200/50-10 | ||||
|
3.4 |
车轮数量，前／后（x＝驱动轮）
Whccls,number front/rcar(x=driven whecls) |
2/2 |
|||||
| 3.5 | 前轮距
Tread,front |
bio |
mm |
1000 | 1080 | ||
| 3.6 | 后轮距
Tread,rear |
bu |
mm |
970 | |||
|
É o 1 U E I O |
4.1 | 门架倾角（前／后）
Tult of mast/fork carriage forward/backward |
a/β | – | 6/10 | ||
| 4.2 | 门架全高
Hcight,mast lowered |
h1 |
mm |
2070 |
2120 |
2180 |
|
| 4.3 | 自由起升高度
Frcc lift |
h2 |
mm |
155 | 155 | 160 | |
|
4.4 |
起升高度（标准）
Lifì |
hs |
mm |
3000 |
|||
| 4.5 | 作业时最大高度（带挡货果）
Height,mast caxtended |
h4 | mm | 4217 | 4217 | 4217 | |
| 4.6 | 护顶架高度
Height of overhead guard |
h6 |
mm |
2180 | 2185 | ||
| 4.7 | 座椅SIP点高度
Scat height/stand height |
b7 |
mm |
1164 | 1164，，， | ||
|
4.8 |
牵引销位置高度
Position beight of traction pin |
hio |
mm |
310 |
310 |
||
|
u l u o u u O |
4.9 |
全长（带货叉）
Overall length |
l1 |
mm |
3637 |
3642 |
3682 |
| 4.1 | 全长（不带货又）
Length to fnce of Foris |
b |
mm |
2567 | 2572 | 2612 | |
| 4.1
1 |
全宽
Overall width |
b1 | mm | 1260 | 1392 | ||
| 4.1
2 |
货叉尺寸：厚x宽x长
Fork dimensionsthick*wide*length |
s/e/
1 |
mm |
45x150x1070 | 50x125x1070 | 50x125x1070 | |
| 4.1
3 |
货叉架，ISO23J0标准
Freight fork ISO 2130 standard |
3A | |||||
| 4.1
4 |
货叉外侧间距，最大／最小
Outside spocing of fork max/min |
bs |
mm |
1060/250 | 1060/250 | 1060/250 | |
| 4.1
S |
离地间隙（满载／门架处）
Ground clearance,Inden,below mast |
m1 |
mm |
110 | 125 | ||
| 4.1
6 |
离地间隙（满载／轴距中心处）
Ground clcarance,centre of wheelbase |
m |
mm | 135 | 140 | ||
| 4.1
7 |
直角堆垛通道宽度，1000×1200横置托盘
Aisle width for pallets 1000 x 1200 crossways |
Aa |
mm |
3912 | 3917 | 3952 | |
| 4.1
8 |
直角堆垛通道宽度，800×1200纵置托盘
Aisle width for pallets 800 x 1200 lengthw4115 ays |
Au |
mm |
4115 | 4117 | 4152 | |
| 4.1
9 |
外侧转弯半径
Tuming radius |
Wa | mm | 2235 | 2235 | 2270 | |
|
2 u 矍也 은 と |
5.1 | 行驶速度（满戲／空载）
Travel spccd,lndcn/unladen |
km/h | 12/13 | 12/13 | ||
| 5.2 | 起升速度（满載／无载）
Lift spocd,ladca/unladcn |
m/
S |
0.290/0.400 | 0.270/0.400 | 0.270/0.400 | ||
| 5.3 | 下降速度（满載／无载）
Lowering spocd,Inden/unladen |
m/
S |
0.400/0.440 | 0.400/0.440 | |||
| 5.4 | 最大牵引力（满載）
Maximum traction(laden) |
N | 16300 | 16900 | |||
| 5.5 | 最大爬坡能力（满載／无载）
Max gradcability,laden/unladen |
% | 15/25 | 15/22 | |||
| 5.6 | 加速时间（10米）（满载／空载）
Acceleration time, laden/unladen (0-10m) |
S | 5.8/5.3 | 6.3/5.4 | 6.2/5.2 | ||
|
こ o I a S |
6.1 | 锂电池电压／容量
Battery voltagc/capacity |
V/A
h |
80/202 | 80/250 | ||
| 6.2 | 蓄电池重量
Battery weight |
kg | 210 | 240 | |||
| J
o l o u 0 6
P u a J 0 1 0 4 |
7.1 | 驱动电机功率S260min
Drive motor rating S2 60 min |
kw | 15 | |||
| 7.2 | 起升电机功率S3 15％
Lif motor rating at S3 15% |
kw | 16 | ||||
| 7.3 | 驱动电机控制方式
Control mode of driving motor |
MOS管／交流 | |||||
| 7.4 | 起升电机控制方式
Control mode of hoisting motor |
MOS管／交流 | |||||
|
ど a 4 0 |
8.1 | 行车制动／停车制动
Scrvice brake/Parking brake |
液力／机械 | ||||
| 8.2 | 属具工作压力
Working pressurc of tools |
Mpa | 16 | ||||
注：由于技术改进，该数据可能与产品不符，如有差异请以产品为准Note: Due to technical improvements, this data may differ from the product. Please refer to the product for accuracy.
